KUHN GF 1003 Mounted Gyrotedders
GF 5202, GF 6502, and GF 7903 tedders are simple, hydraulic-folding, cost-effective tools with 4 to 8 rotors and working widths from 5.20 m to 7.80 m. They are the perfect machine for farmers with relatively small areas to ted annually.
Opt for a large-rotor tedder to work in long and dense forage, and a small-rotor tedder for short forage, with uniform crop-turning and faster drying. GF 8703 and GF 10803 tedders feature 8 and 10 rotors respectively, and work at widths of 8.70 m and 10.80 m.
Features & Benefits
The compact machines have been specially designed for optimum road safety. KUHN's DIGIDRIVE system and rotor gearboxes are lubed-for-life, keeping maintenance time down to a minimum.
- Narrow plots and points are no trouble thanks to the HLC rotor-lift system (Headland Lift Control). Simply activate the valve to lift all rotors to minimum 50 cm from the ground, in less than 5 seconds.
- The large-diameter rotors have been specially designed to handle long, woody, and dense forage. These machines also provide an excellent working width to cost ratio.
- The asymmetrical tine length, with a longer outer tine, offers certain advantages for quality tedding. Compared to a symmetrical design, the outer tine engages the forage sooner. This ensures complete forage pickup, even at field edges, but also between the rotors, with better tine coverage in this sensitive area. Working the forage earlier means that the effective working width of each rotor, and therefore of the machine, is greater.
Specifications
| GF 5202 | GF 6502 | GF 7903 | GF 8703 | GF 10803 | |
| Working width DIN (m) | 5.2 | 6.5 | 7.8 | 8.7 | 10.80 |
| Overall width in working position (m) | 5.85 | 6.96 | 8.37 | 9.10 | 11.20 |
| Number of rotors | 4 | 6 | 8 | 8 | 10 |
| Number of tine arms per rotor | 7 | 6 | 5 | 6 | 6 |
| Transport width (m) | 2.99 | 2.99 | 2.99 | 2.99 | 2.99 |
