KUHN GMD 1030 Disc Mower
You can count on the performance, quality of work and reliability of our GMD 1030 Disc Mower range. GMD triple gang mowers help you to reach your goals in terms of output and quality - without compromise. GMD triple gang mowers are available in three versions, designed for tractors from 120 hp: GMD 8730 (8.30 to 8.80 m), GMD 9530 (9.13 to 9.53 m), GMD 10030 (9.53 to 9.93 m).
Attach a GMD 3125 F or a GMD 3525 F at the front of the tractor to benefit from the same techniques as the rear unit.
Features & Benefits
This range provides maximum work output without compromising on the quality of the harvested forage. Intended for contractors, machinery cooperatives and large farms.
- The adjustment adapted by the suspension system limits the introduction of impurities in the forage and reduces the ground pressure of the cutter bar.
- Variable spacing between discs, large overlap zones and the reduced angle of the OPTIDISC cutter bar will provide you with the quality you need.
- In the event of a very violent impact, pre-defined breakage groves protect the drive modules and ensures the machine is quickly (within 15 minutes) back up and running at a low repair cost.
- The mowing units can be offset sideways by 20 cm to increase the overlap between the front and rear units.
Specifications
| 8730 | 9530 | 10030 | |
| Working width (m) | 8.30 – 8.80 | 9.13 – 9.53 | 9.53 – 9.93 |
| Transport width (m) | 2.99 | 2.95 | 3.35 |
| Number of disks | 2 x 7 | 2 x 8 | 2 x 8 |
| Average swath width (m) | 2 x 2.4 | 2 x 2.8 | 2 x 2.8 |
| PTO speed (rpm) | 1000 | 1000 | 1000 |
