Väderstad NZ Extreme Tine Harrow
Precision and capacity taken to the extreme. The 12.5 to 14.25 metre heavy-duty Vaderstad NZ Extreme tine harrow levels the field and creates an ideal seedbed for the coming crop.
NZ Extreme is able to perform high-capacity seedbed preparation in a wide range of field conditions – from ploughed to cultivated land. NZ Extreme offers unmatched capacity combined with a high intensity work result. This reduces the passes needed and retains moisture in the ground.
Features & Benefits
To ensure exact field contour following precision NZ Extreme has a 5-section frame, able to adapt to the field surface and maintain the selected depth. This is further increased by an innovative weight transfer, ingenious wheel setup and heavy-duty machine design.
- Wide wheels distributed across the machine length and width, creates a high carrying capacity and ensures same conditions for each tine.
- CrossBoard provides an aggressive cultivation, ensuring that clods are crushed, and the soil is levelled. The working intensity is easily controlled hydraulically from the cab.
- The double-acting stabiliser bar ensures that all CrossBoard tines work together as one unit, preventing individual tines to move forward or backward.
Specifications
| 1250 | 1425 | |
| Effective working width (m) | 12.50 | 14.25 |
| Transport width (m) | 3.49 | 3.49 |
| Number of tines | 161 | 181 |
| Tine spacing (cm) | 7.7 | 7.8 |
| Draught requirements from (hp) | 300-500 | 350-600 |
