Landini Rex4 F-S-GE-GB-GT-V
The REX4 range introduces profound technical and functional improvements. Its ability to meet the most exacting demands of modern farming marks a breakthrough in the speciality tractor segments in terms of technologies, ergonomics, comfort, flexibility and design. Cab, with F, S, GT, V models. ROPS with F, GE, GB, GT.
The range offers a choice of transmissions and a variety of front and rear axles providing different wheelbase sizes, ground clearances and track widths.
Features & Benefits
The REX4 is equipped with the state-of-the-art generation of Deutz-AG TCD Stage V, 2.9-litre, 4-cylinder engines from 75 to 112 HP, Turbo intercooler and Common Rail electronic injection. With a maximum power of between 1,500 and 2,000 rpm, these engines are outstandingly efficient: they deliver higher power, cut fuel consumption, and offer greater versatility in use.
- The REX4 is equipped with a Speed Four transmission: 4 synchronised gears and 3 mechanical speed ranges, for a total of 12 FW + 12 RV. With the Creeper it reaches 16 FW + 16 RV.
- The new REX4 hydraulic system is more flexible than ever before, to guarantee each and every farmer tailored solutions that meet their individual requirements. The standard hydraulic system features a double pump that sup plies 58 + 30 l/min to the rear hitch and the spool valves, and 30 l/min to the steering system.
- The Lounge Cab is a true mobile office where working becomes fun. Its 4-post structure guarantees 360° all-round visibility. In addition, easy access thanks to the hinged doors at the rear, the clear flat-deck platform, adjustable operator driving seat, ergonomic controls, automotive inspired materials and air conditioning make this cab a perfect working environment whatever the season.
Specifications
|
REX4-080 F-S-GE-GB-GT-V |
REX4-090 F-S-GE-GB-GT-V |
REX4-100 F-S-GE-GB-GT-V |
REX4-110 F-S-GE-GB-GT-V |
REX4-120 F-S-GE-GB-GT-V |
|
| Rated power (ISO) (hp) | 75 | 79 | 86 | 95 | 105 |
| Maximum power (ISO) (hp) | 75 | 90 | 95 | 102 | 112 |
| Maximum torque (Nm) | 375 | 378 | 400 | 410 | 120 |
| Transmission type | Power four, 24 x 24 with hi/lo | Power four, 24 x 24 with hi/lo | Power four, 24 x 24 with hi/lo | Power four, 24 x 24 with hi/lo | Power four, 24 x 24 with hi/lo |
| Maximum lifting capacity at hitch points (kg) | 2700 | 2700 | 2700 | 2700 | 2700 |
| Gross vehicle weight (kg) | 5250 | 5250 | 5250 | 5250 | 5250 |
