KUHN RW Bale Wrapper
The KUHN RW 1810 high-capacity inline bale wrapper is equipped with the latest technologies. A laser operated AUTOLOAD system detects the approaching bale and sets the loading arm into the pre-load position. The unique loading system, with its loading arm integrated into the wrapping table, allows the bale to gently roll onto the wrapping table without extra process steps.
The twin satellite arms with pre-stretchers, wrap the bale at high speeds soon after loading the bale. An option of 3D wrapping and intelliwrap further increase the quality of the forage. Once the correct amount of film layers are applied, the film is cut and firmly held by the 'scissors-type' film cutters.
Features & Benefits
The pre-stretchers, film cutters, wrapping table, and low-profile chassis design make KUHN bale wrappers simple, easy-to-use, fast, and efficient.
- The wrapping table features two rollers and four wide, spaced belts for a deep and stable cradle for the bale.
- The unique loading system makes the wrapper suitable for loading 1400 kg bales with 100-160 cm in diameter.
- 100% fully automatic loading, wrapping and unloading without having to press a button.
Specifications
| RW 1810 | |
| Bale dimensions (width x diameter) (cm) | 120 x 100-160 |
| Max bale weight (kg) | 1200 (with 180 bar) / 1400 (with 200 bar) |
| Machine width (cm) | 279 |
| Wrapping table | 4 belts |
| Pre-stretch ratio | As standard 70% (60% optional) |
